사양→ |
응축열량(kcal/h) |
전열면적
(㎡) |
접속관경(￠) |
휀&모터
(￠xkwxPxEA) |
풍량
(CMM) |
외형치수(LxWxH) |
앵커치수
(L″xW″) |
중량(kg) |
|
모델↓ |
IN |
OUT |
|
CU-V030 |
9950 |
26 |
22.22 |
12.70 |
500x0.1x8x1 |
57 |
770x740x805 |
650x280 |
67 |
|
CU-V050 |
16600 |
41 |
22.22 |
12.70 |
600x0.2x8x1 |
95 |
920x840x950 |
800x305 |
84 |
|
CU-V075 |
24900 |
63 |
28.58 |
15.88 |
500x0.1x8x2 |
143 |
1320x740x955 |
1200x285 |
110 |
|
CU-V100 |
33200 |
83 |
34.92 |
19.05 |
600x0.2x8x2 |
190 |
1610x840x1000 |
1490x310 |
140 |
|
CU-V150 |
49800 |
125 |
41.28 |
22.22 |
650x0.4x8x2 |
285 |
1625X930X1000 |
1505x340 |
170 |
|
CU-V200 |
66400 |
163 |
41.28 |
28.58 |
750x0.4x8x2 |
380 |
2070x1030x1000 |
1950x440 |
210 |
|
CU-V250 |
83000 |
204 |
53.98 |
28.58 |
700x0.4x8x3 |
475 |
2540x980x1000 |
2420x390 |
270 |
|
CU-V300 |
96600 |
277 |
53.98 |
28.58 |
750x0.4x8x3 |
570 |
2740x1050x960 |
2620x460 |
315 |
|
CU-V400 |
132800 |
332 |
53.98 |
28.58 |
700x0.4x8x4 |
680 |
2230x1863x1307 |
1910x945 |
450 |
|
CU-V500 |
166000 |
416 |
53.98 |
28.58 |
600x0.2x8x6 |
690 |
2260x1705x1240 |
1940x790 |
560 |
|
CU-V600 |
199200 |
547 |
79.38 |
41.28 |
650x0.4x8x6 |
735 |
2730x1805x1240 |
2410x890 |
650 |
|
