사양→ |
응축열량(kcal/h) |
전열면적
(㎡) |
접속관경(￠) |
휀&모터
(￠xkwxPxEA) |
풍량
(CMM) |
외형치수(LxWxH) |
앵커치수
(L″xW″) |
중량(kg) |
|
모델↓ |
IN |
OUT |
|
CU-Ⅱ015 |
5850 |
10 |
19.05 |
12.70 |
400x0.1x6x1 |
45 |
775x412x535 |
685x322 |
43 |
|
CU-lO015 |
775x161x535 |
708x186 |
29 |
|
CU-Ⅱ020 |
7800 |
21 |
19.05 |
12.70 |
400x0.1x6x1 |
45 |
775x412x635 |
685x322 |
47 |
|
CU-lO020 |
747x161x635 |
708x186 |
32 |
|
CU-Ⅱ030 |
9950 |
28 |
22.22 |
15.88 |
400x0.1x6x2 |
90 |
1775x412x535 |
1085x322 |
66 |
|
CU-lO030 |
1147x161x535 |
1108x186 |
47 |
|
CU-Ⅱ040 |
13280 |
34 |
22.22 |
15.88 |
400x0.1x8x2 |
90 |
1175x412x635 |
1085x322 |
72 |
|
CU-lO040 |
1147x161x635 |
1108x186 |
52 |
|
CU-Ⅱ050 |
16600 |
50 |
28.58 |
19.05 |
500x0.1x8x2 |
120 |
1275x434x635 |
1185x344 |
87 |
|
CU-lO050 |
1247x183x635 |
1208x208 |
66 |
|
CU-Ⅱ060 |
19920 |
52 |
28.58 |
19.05 |
500x0.1x8x2 |
120 |
1325x434x635 |
1235x344 |
89 |
|
CU-lO060 |
1297x183x635 |
1258x208 |
67 |
|
CU-Ⅱ075 |
24900 |
65 |
34.92 |
19.05 |
500x0.2x8x2 |
140 |
1345x456x635 |
1255x366 |
98 |
|
CU-lO075 |
1317x205x635 |
1278x230 |
74 |
|
CU-Ⅱ085 |
28220 |
78 |
34.92 |
19.05 |
500x0.2x8x2 |
140 |
1345x478x635 |
1255x388 |
102 |
|
CU-lO085 |
1317x227x635 |
1278x252 |
81 |
|
CU-Ⅱ100 |
33200 |
101 |
41.28 |
22.22 |
450x0.1x8x3 |
210 |
1695x478x635 |
1605x388 |
139 |
|
CU-lO100 |
1667x227x635 |
1628x252 |
108 |
|
